Vibration Isolation Case Studies
DAEIL SYSTEMS engineers active vibration isolation systems for the world's most demanding nanoscale imaging and metrology environments.
Series
Equipment Type
Manufacturer
All Case Studies
Seoul National University DVIA-T56 (130123R3) Installation Report
DVIA-T56 (serial 130123R3) tuning and vibration measurement at Samsung Leaders Building Room 1104 — level foot rework, equipment-not-installed condition; VC curves, autospectrum, and transmissibility by axis.
Tier-1 Semiconductor Cheonan C5 ZEISS Crossbeam 550 FIB-SEM DVIA-ML1000 (240710R2) Installation Report
DVIA-ML1000 installation report (serial 240710R2) for ZEISS FIB-SEM Crossbeam 550 at Tier-1 Semiconductor Cheonan C5. Overview describes on-site tuning and vibration measurement with the tool in IDLE after placement; measurement setup and equipment vibration limit VC-E appear in the specification capture. Measurement Summary includes a vertical floor line FAIL with platform PASS; horizontal axes PASS. Published plots: vibration specification capture, VC / Autospectrum / Transmissibility by axis. Reference uses the standard Generic Vibration Criteria markdown table only (no separate reference graphic).
YIMO Ciqtek High Speed SEM HEM6000 DVIA-M1000 (241101R6) Installation Report
DVIA-M1000 installation report (serial 241101R6) — Ciqtek High Speed SEM HEM6000. YIMO field package. UI-program transmissibility plots and equipment photo; Reference as markdown VC table.
YIMO Ciqtek High Speed SEM HEM6000 DVIA-M1000 (241101R9) Installation Report
DVIA-M1000 installation report (serial 241101R9) — Ciqtek High Speed SEM HEM6000. YIMO field package. UI-program transmissibility plots and equipment photo; Reference as markdown VC table.
Xiamen Street Lighting Institute Thermo Fisher Scientific Talos DVIA-M-THT3 (240807R5) Internal Program Performance — 2024.12.05
DVIA-M-THT3 serial 240807R5 — handout for Xiamen Street Lighting Institute, target equipment Thermo Fisher Scientific Talos, installation Xiamen. Overview and measurement metadata match the published form; M-THT3 internal program performance plots labeled Vertical, Left to Right, and Front to Back from the UI program. Cover-only header graphics are not republished.
Seohan Technology Research Institute JEOL JSM-IT500 DVIA-M1000 Installation Report — 2024.12.04
DVIA-M1000 (serial 171009R1 on the issued form; Word filename revision 171009R2) tuning and vibration measurement at Seohan Technology Research Institute — 3F materials testing lab. JEOL SEM JSM-IT500 with Data Physics QUATTRO and PCB 393B05. Nine-axis VC / Autospectrum / Transmissibility plots plus an equipment photograph; opening JEOL tagline raster and the appendix reference raster are not republished — ISO/VC criteria appear as the site markdown table.
