Vibration Isolation Case Studies

DVIA-MB3000 (serial 241011R1) on-site tuning and vibration worksheet at Tier-1 Display Manufacturer Giheung. Measurement curves and UI plots are not published on this page owing to customer site data-handling restrictions; the written findings, measurement summary table, and the equipment vibration specification diagram from the installation report are provided. DAEIL SYSTEMS field engineer Chae-won Lee; report written 2024.11.29.

DVIA-ML1000 installation report (serial 240821R5) for Unisoki Low Temperature SPM USM1200 at Yonsei University Quantum Imaging Laboratory, Advanced Science and Technology Research Building. Tuning and vibration measurement on November 19, 2024; report dated November 21, 2024. Engineer Chaewon Lee (DAEIL SYSTEMS). Equipment status: 장비 설치 및 IDLE. Brüel & Kjær LAN-XI DAQ Type 3050 and PCB 393B05 accelerometer; measurement setup 200 Hz span, 800 lines, Hanning, m/s. Conclusion states all axes meet the vibration specification and notes amplification in some bands is inherent USM1200 vibration. Measurement summary PASS all axes. Published plots: vibration specification UI, VC / Autospectrum / Transmissibility for Vertical, Left to Right, and Front to Back, plus equipment photo. Reference uses the standard Generic Vibration Criteria markdown table only (no separate reference graphic).

DVIA-M1000 installation report (serial 240701R5) for Hitachi FE-SEM SU8600 via YIMO. Overview matches the published form. Equipment condition: The equipment is installed / Operation. Published figures include UI-program plots as listed; Reference uses the standard Generic Vibration Criteria markdown table.

DVIA-M-THT3 onboard program measurement screenshots (serial 240807R5) for Thermo Fisher Scientific Talos TEM at END USER Xiamen Street Lighting Institute — Xiamen site. Operator Chaewon Lee; setup and reporting 24.11.18; measurement 2024.11.18 (Monday). Published captures follow the embedded program headings Vertical, Left to Right, and Front to Back; decorative title-block raster before the summary tables is omitted.

DVIA-M1000 installation report (serial 240828R1-5) — HITACHI FE-SEM SU8600. YIMO field package. UI-program transmissibility plots and equipment photo; Reference as markdown VC table.

DVIA-MB3000 (serial 141104R5) inspection and tuning after relocation to Korea Electronics and Machinery Convergence Technology Institute, Room 104, with measurement on 31 Oct 2024 and report dated 15 Nov 2024. Equipment not yet installed; VC-curve, autospectrum, and transmissibility plots for vertical, left-to-right, and front-to-back axes; measurement summary per the site worksheet; equipment vibration specification TBD (미정). Engineers Chae-won Lee (field) and Dong-hwan Kim (domestic sales), DAEIL SYSTEMS. Reference uses the standard Generic Vibration Criteria markdown table (no separate reference figure).
