Vibration Isolation Case Studies

DVIA-M1000 installation report (serial 240509R7-3) for ZEISS FE-SEM Sigma360 via YIMO. Overview matches the published form. Equipment condition: The equipment is installed/Turned off. Published figures include UI-program plots as listed; Reference uses the standard Generic Vibration Criteria markdown table.

DVIA-STONE-300 handout (serial 240513R3) titled (STONE-300_ 240513R3 Set up) with setup 24.11.13 and reporting 24.11.14. Thermo Fisher Spectra 300 target equipment is recorded at Southern University of Science and Technology, Shenzhen. The Overview paragraph, operator lines, and equipment labels follow the report text; the worksheet shows STONE-300 internal program screenshots under Vertical, Left to Right, and Front to Back. The source has no standalone vibration specification section, measurement summary table, or Reference section.

DVIA-M1000 handout from M-OST_240724R3_2024.11.12.docx (serial 240724R3) for Suzhou Institute of Nanotechnology with target equipment Omicron STM in Suzhou. Overview and in-form metadata match the worksheet; M1000 internal program screenshots are labeled Vertical, Left to Right, and Front to Back. The JPEG embedded under the `(M-OST_24724R3 - Set Up)` title line (rId8 / image1.jpeg) was treated as header decoration and omitted from the public page. No vibration specification, equipment status, tuning request, measurement summary table, or Reference section appears in the source.

DVIA-MB3000 (serial 171201R2) on-site vibration worksheet dated 2024.11.11 at Tier-1 Semiconductor with upper-platform equipment Turned off: passive setting, active tuning, and vibration measurements. VC-curve plots for floor vs platform (passive control off and DVIA-MB3000 Active On), measurement summary table, equipment vibration specification diagram, and Reference as a markdown Generic Vibration Criteria table (no separate reference figure). Engineer Jung Sung-yoon (DAEIL SYSTEMS); report written 2024.11.18.

DVIA-M1000 installation report (serial 240823R3) for ZEISS FE-SEM Sigma360 via YIMO. Overview matches the published form. Equipment condition: The equipment is installed/Turned off. Published figures include UI-program plots as listed; Reference uses the standard Generic Vibration Criteria markdown table.

DVIA-M1000 installation worksheet (serial 231219R4, source M1000_231219R4_24.11.08.docx). Measurement date 2024-11-08 with operator Chaewon Lee (DAEIL SYSTEMS); target equipment ZEISS Crossbeam 350 FIB-SEM. END USER and place of installation appear as “-” on the form — published checklist uses N/A. No vibration specification, equipment status, tuning request, measurement summary table, or Reference section in the source. The internal-program section title reads “M1000 internal program performance measurement result” with Vertical, Left to Right, and Front to Back plots. Decorative header imagery on the Set-up line was omitted from the public page.
