Vibration Isolation Case Studies

DVIA-M1000 installation report (serial 231009R3) for ZEISS Sigma300 SEM at Xi’an Jiaotong University. Internal M1000 program performance plots: vertical, left-to-right, and front-to-back transmissibility with coherence; equipment installation photo; site summary and overview from the issued form. Reference uses the standard Generic Vibration Criteria markdown table only.

DVIA-M1000 installation report (serial 240827R2) for ZEISS FE-SEM Sigma360. Overview matches the published form. Equipment condition: The equipment is installed/Turned off. Published figures include UI-program plots as listed; Reference uses the standard Generic Vibration Criteria markdown table.

DVIA-M1000 installation report (serial 241106R4) — ZEISS SEM EVO 15. Field package. UI-program transmissibility plots and equipment photo; Reference as markdown VC table.

DVIA-M1000 installation report (serial 240415R3-3) for Thermo Fisher Scientific Helios G5 FIB-SEM, prepared for Shenzhen Weiguang in Shenzhen, China. Overview states the platform is appropriately installed and functioning as intended. The published form has no separate vibration specification section or measurement summary table. Equipment condition: The equipment is installed/IDLE. Tuning Request UI capture; vertical, left-to-right, and front-to-back transmissibility; on-site equipment photo under section 10; Reference uses the standard Generic Vibration Criteria markdown table (no separate reference graphic).

DVIA-M1000 installation report (serial 241106R6) — ZEISS FE-SEM Sigma360. Field package. UI-program transmissibility plots and equipment photo; Reference as markdown VC table.

DVIA-MB3000 (serial 241011R1) on-site tuning and vibration worksheet at Tier-1 Display Manufacturer Giheung. Measurement curves and UI plots are not published on this page owing to customer site data-handling restrictions; the written findings, measurement summary table, and the equipment vibration specification diagram from the installation report are provided. DAEIL SYSTEMS field engineer Chae-won Lee; report written 2024.11.29.
