Thermo Fisher Scientific Apreo ChemiSEM S HiVac DVIA-ML1000 Installation Report

DVIA-ML1000 (serial 260716R4) installation report for a Thermo Fisher Scientific Apreo ChemiSEM S HiVac at the Aeolus Tyres site in Jiaozuo. Tuning and vibration measurement were performed on 2026.10.29 with the equipment in the Idle state. The floor exceeds the VC-F specification in the Vertical and Front to Back axes, while the isolator meets VC-F in all three axes.

HEM6000 SEM DVIA-MB1000 (S/N 250514R3) Installation Report
Installation Report
DVIA-M Series
10-27-2026

HEM6000 SEM DVIA-MB1000 (S/N 250514R3) Installation Report

Installation report for the DVIA-MB1000 (S/N 250514R3) supporting a CIQTEK HEM6000 SEM at Westlake University in Hangzhou. After installation at the Hangzhou site, tuning and vibration measurement were performed with the equipment in the IDLE state. On the floor the Vertical and Front to Back axes exceeded the specification (FAIL), while on the DVIA-MB1000 all three axes met the allowable limits (PASS). Per-axis autospectrum and the installation photo are published.

ZEISS FE-SEM DVIA-ML1000 Installation Report
Installation Report
DVIA-M Series
10-22-2026

ZEISS FE-SEM DVIA-ML1000 Installation Report

DVIA-ML1000 (serial 260617R5) installation report for a ZEISS FE-SEM Sigma 360 at the PipeChina site in Tianjin. Tuning (1st trial) was performed on 2026.10.22 with the equipment in the Idle state; floor vibration exceeded the ZEISS specification in all three axes while the isolator met the specification in all three axes.

AOV CO.,LTD GBS smartWLI Firebolt8 WLI DVIA-T56 (260813R3) Installation Report

Installation report for the DVIA-T56 (serial 260813R3) under a GBS metrology GmbH WLI (GBS smartWLI Firebolt8) at AOV CO.,LTD in Taipei, Taiwan. After remote tuning to resolve an oscillation issue, vibration measurements in the turned-on state met the customer-specified VC-D criterion (vertical VC-G, left-to-right VC-E, front-to-back VC-G on the tabletop).

ZEISS Sigma 360 FE-SEM DVIA-ULF700 Installation Report
Installation Report
DVIA-ULF Series
10-20-2026

ZEISS Sigma 360 FE-SEM DVIA-ULF700 Installation Report

Installation report of DVIA-ULF700 (S/N 260902R5) at Linhai, Zhejiang for (End User: Xintaijia Optoelectronics), serving a ZEISS Sigma 360 FE-SEM. Tuning and vibration measurement were performed in the Idle state with data in Autospectrum format; a structural resonance near 10 Hz on the horizontal X-axis was suppressed by controller tuning, and the DVIA-ULF700 met the customer vibration specification on all axes.

JEOL JSM-IT300 SEM DVIA-ML1000 Installation Report
Installation Report
DVIA-M Series
10-16-2026

JEOL JSM-IT300 SEM DVIA-ML1000 Installation Report

DVIA-ML1000 installation report (serial 260825R5) for a JEOL JSM-IT300 SEM at Jiangyin, supplied for end user Jiangyin Xingcheng Special Steel Works Co., Ltd. Tuning and vibration measurement were performed on 2026.10.16 with the equipment in the IDLE state, and all axes at the floor and on the isolation system passed the 2 µm pk-pk vibration specification.
