DVIA-M1000 abbreviated worksheet (serial 230706R2; intake filename M1000_2307060R2_24.08.19.docx — body spells 230706R2). Setup dated 24.08.19 and reporting dated 24.12.04; measurement date 2024.08.19 (Monday) in Shanghai with operator Chaewon Lee from DAEIL SYSTEMS. END USER Donghua University; target equipment HITACHI SU7000 and place of installation Shanghai as in the form. The Overview block states the standard DVIA-M1000 sentence only. No vibration specification, equipment status, tuning request, measurement summary table, or Reference section appears in the source. The internal-program section title in the source reads “M1000 internal program performance measurement result”; published figures are three plots labeled Vertical, Left to Right, and Front to Back. Decorative header graphics from the Word file are omitted from public copy.

DVIA-M1000 installation report (serial 231009R3) for ZEISS Sigma300 SEM at Xi’an Jiaotong University. Internal M1000 program performance plots: vertical, left-to-right, and front-to-back transmissibility with coherence; equipment installation photo; site summary and overview from the issued form. Reference uses the standard Generic Vibration Criteria markdown table only.

DVIA-M1000 installation report (serial 240827R2) for ZEISS FE-SEM Sigma360 via YIMO. Overview matches the published form. Equipment condition: The equipment is installed/Turned off. Published figures include UI-program plots as listed; Reference uses the standard Generic Vibration Criteria markdown table.

DVIA-M1000 installation report (serial 241106R4) — ZEISS SEM EVO 15. YIMO field package. UI-program transmissibility plots and equipment photo; Reference as markdown VC table.

DVIA-M1000 installation report (serial 240415R3-3) for Thermo Fisher Scientific Helios G5 FIB-SEM via YIMO, prepared for Shenzhen Weiguang in Shenzhen, China. Overview states the platform is appropriately installed and functioning as intended. The published form has no separate vibration specification section or measurement summary table. Equipment condition: The equipment is installed/IDLE. Tuning Request UI capture; vertical, left-to-right, and front-to-back transmissibility; on-site equipment photo under section 10; Reference uses the standard Generic Vibration Criteria markdown table (no separate reference graphic).

DVIA-M1000 installation report (serial 241106R6) — ZEISS FE-SEM Sigma360. YIMO field package. UI-program transmissibility plots and equipment photo; Reference as markdown VC table.
