Vibration Isolation Case Studies

DVIA-ULFB1000 (serial 250711R2) installation report for COXEM (End User) with a ZEISS FE-SEM SUPRA 55VP at Migun Techno World Phase 1, Room 2209, Daejeon. Vibration measurement and tuning on 27 Aug 2025 with the tool installed and turned off. Includes vertical and horizontal vibration specification figures, axis VC curves, autospectra, transmissibility, equipment photo, and the standard VC reference table.

COXEM DVIA-ULFB1000 Installation Report

DVIA-M1000 installation report — ZEISS FE-SEM GeminiSEM 360 (serial 250530R5-1) for Tianjin Institute of Hematology in Tianjin, China. Overview states the platform is appropriately installed and functioning as intended. Equipment condition: The equipment is installed / Turned off. Published figures: tuning-request UI-program capture, Transmissibility (vertical, left-to-right, front-to-back), and on-site equipment photo. No vibration-specification section, measurement-summary table, or VC or Autospectrum figures; Reference uses the generic vibration-criteria markdown table.

DVIA-M1000 installation report — ZEISS FIB-SEM Crossbeam 550 (serial 250530R5-2) for Tianjin Institute of Hematology in Tianjin. Overview states the platform is appropriately installed and functioning as intended. The published form has no separate vibration specification section. Equipment condition: The equipment is installed/Turned off. Tuning request as UI-program capture; vertical, left-to-right, and front-to-back transmissibility; on-site equipment photo; Reference uses the standard Generic Vibration Criteria markdown table. Report written date taken from the cover block.

DVIA-M1000 installation report (serial 240927R2-1) — Hitachi TEM HT7800. YIMO field package. UI-program transmissibility plots and equipment photo; Reference as markdown VC table.

DVIA-M1000 installation report (serial 240927R2-2) — Hitachi FE-SEM SU8600. YIMO field package. UI-program transmissibility plots and equipment photo; Reference as markdown VC table.
