Vibration Isolation Case Studies

DVIA-MB1000 installation report (serial 230518R2) for JEOL JSM-7001F at POSCO Global R&D center (Songdo). Summary of vibration results (VC-class table), Z/X/Y VC curves and transmissibility plots; Reference uses the standard Generic Vibration Criteria markdown table (reference graphic omitted). Decorative header image from the Word file is not published.

DVIA-M1000 handout archived as M1000_230525R8_23.09.07. Installation summary targets Shenzhen with remark Good Performance and END USER PXW. Overview states the DVIA-M1000 platform is appropriately installed and functioning as intended. Published figures are the three M1000 internal-program UI screenshots (Z, X, and Y axes) only; PXW title-block déc raster is omitted. The source worksheet has no vibration specification, measurement summary table, or Reference section.

DVIA-MO1000 Set Up Report (serial 230608R2) for STM at Lee Tsung-Dao Research Institute, Shanghai. MO1000 internal program performance plots for vertical, left-to-right, and front-to-back directions; compact report without measurement summary table or reference VC figure.

DVIA-M1000 handout for serial 230701R3 with ZEISS Sigma300 target equipment at Shanghai Institute of Space Propulsion. Overview, setup and reporting dates, measurement session on 2023.10.10, and laboratory photograph. M1000 internal program performance screenshots for Z, X, and Y axes. Reference and vibration-limit tables were not included in this handout.

DVIA-MB1000 installation report (serial 230704R4) for ZEISS FE-SEM EVO10 at Jinhae Armed Forces Financial Management Command. Published figures: ZEISS EVO10 specification VC curve (equipment vibration limits), Vertical / Left-to-right / Front-to-back Transmissibility and VC curves. Reference uses the standard Generic Vibration Criteria markdown table only (no separate reference graphic).

DVIA-M1000 Gemini 560 handout archived as M1000_230804R2_23.09.04. Summary rows list Nanjing, remark Good Performance, and end user LG. Overview states the DVIA-M1000 platform is appropriately installed and functioning as intended. Measurement lines and equipment model Gemini 560 precede UI plots under M1000 internal program performance measurement result for Z / X / Y axes. Published images are those three screenshots only; LG title-block déc raster omitted.
