Vibration Isolation Case Studies

DVIA-ML1000 installation report — Hitachi SEM SU3800 (serial 250423R3) at Henkel Adhesive Technologies India Private Limited, 6th floor SEM room. Overview states the DVIA-ML1000 functions properly as intended. The report embeds distinct figures under Vibration Specification and under each Data & Images subheading on the form sequence: Narrow Band displacement plots (“Vibration (Narrow Band)”), VC-referenced velocity “Vibration” plots by axis, and transmissibility by axis from the measurement software; onsite equipment portrait; Generic Vibration Criteria table as Reference.

DVIA-M1000 installation report (serial 250220R4). Published figures: vertical-transmissibility, left-to-right-transmissibility, front-to-back-transmissibility, equipment-picture-01. Reference uses the standard Generic Vibration Criteria markdown table.

DVIA-M1000 serial 191211R3 worksheet for ZEISS SEM model EVO 10: overview and metadata from the issued handout; M1000S setup photograph and M1000 internal-program performance UI captures for Vertical, Left to Right, and Front to Back. Place of installation, end user, and several table cells are given as “-” on the form and are reproduced the same way.

DVIA-T67 (serial 250204R2) tuning and vibration measurement at Korea Institute of Nano Technology 3F QRT lab for customer QRT, May 13, 2025. MSTech MST8500 probe station; equipment installed and Operation during measurement; overall isolator performance tuning (not probing-environment-specific). Floor VC-C/B/C reduced to VC-F/F/G by axis; VC curves, autospectra, transmissibility, and equipment photo published; Reference as markdown table.

KIMM L2A laboratory Self-made equipment stack DVIA-P550 tuning and vibration measurement (Installation Report)

KIMM Self-made DVIA-P550 Installation Report
