Vibration Isolation Case Studies
DAEIL SYSTEMS engineers active vibration isolation systems for the world's most demanding nanoscale imaging and metrology environments.
Series
Equipment Type
Manufacturer
All Case Studies
ZEISS DEMO Laboratory Sigma 360 VP DVIA-M1000 Installation Report (Shanghai)
ZEISS DEMO Laboratory — Sigma 360 VP FE-SEM on DVIA-M1000 (SN 220121R3); internal program screenshots for Vertical, Left to Right, and Front to Back in Shanghai.
YIMO Zeiss FE-SEM Sigma360 DVIA-M1000 (250102R2-4) Installation Report
DVIA-M1000 installation report (serial 250102R2-4). Published figures: tuning-request, vertical-transmissibility, left-to-right-transmissibility, front-to-back-transmissibility, equipment-picture-01. Reference uses the standard Generic Vibration Criteria markdown table.
Shanghai ZEISS Sigma360 DVIA-U1000 (250114R3) Installation Report
DVIA-U1000 compact installation worksheet (serial 250114R3) for ZEISS FE-SEM Sigma360 in Shanghai. Setup 25.04.15, report written 25.04.18, business-trip line 17.12.27~17.12.29; engineer Chaewon Lee. Overview notes insufficient performance due to a resonance peak around 20–50 Hz. Publishes setup photograph and U1000 internal-program Vertical / Left to Right / Front to Back performance screenshots.
Shanghai Tight Welding Institute ZEISS SEM EVO10 DVIA-U1000 (241217R6) Installation Report — Shanghai
DVIA-U1000 compact installation worksheet (serial 241217R6) at Shanghai Tight Welding Institute with ZEISS SEM EVO10 in Shanghai. Setup 2025.04.17; reporting 2025.04.18; Overview measurement dated 2025.04.17 (Thursday); business-trip line 17.12.27~17.12.29. Publication includes installation photograph plus U1000 internal-program Vertical / Left-to-Right / Front-to-Back screenshots in Word segment order.
YIMO Zeiss FE-SEM Sigma360 DVIA-M1000 (250220R1) Installation Report
DVIA-M1000 installation report (serial 250220R1). Published figures: tuning-request, vertical-transmissibility, left-to-right-transmissibility, front-to-back-transmissibility, equipment-picture-01. Reference uses the standard Generic Vibration Criteria markdown table.
YIMO DVIA-M1000 (240320R1) Installation Report
DVIA-M1000 installation report (serial 240320R1) via YIMO. Overview states the platform is appropriately installed and functioning as intended. Prepared for, location, end user, and equipment manufacturer fields are N/A on the form. Equipment condition: The equipment is installed/IDLE. Tuning request N/A. Second tuning trial (first trial March 12, 2025). UI-program vertical, left-to-right, and front-to-back transmissibility plots; Reference uses the standard Generic Vibration Criteria markdown table (no separate reference graphic).
