Vibration Isolation Case Studies

DVIA-STONE-300 internal program handout (serial 240415R3-1) with Thermo Fisher Scientific Spectra 300 S/TEM as target equipment. Measurement 2024-07-25; published figures are vertical, left-to-right, and front-to-back internal program results; decorative title-block raster omitted from web. Generic Vibration Criteria published as markdown table only (no separate VC figure).

DVIA-STONE-300 (serial 231113R4-1) STONE internal program performance captures for Thermo Fisher Spectra 300 TEM at the Shanghai Institute of Ceramics, Chinese Academy of Sciences — Analysis & Testing Research Center. Overview, system lines, and metadata follow the report wording; only Vertical, Left to Right, and Front to Back plots are published. The decorative raster inserted under the (STONE-300_ 231113R4-1 Set up) title block in the DOCX is omitted from the public page.

DVIA-STONE-300PLUS worksheet (serial 210824R1-1) titled (STONE-300PLUS_ 210824R1-1 Set up) with setup 24.07.19 and reporting 24.07.20. Target equipment is Thermo Fisher Spectra 300 TEM for Peking University Huairou (北大怀柔) with installation place 北京. Overview and field lines follow the report verbatim; STONE-300PLUS internal program screenshots are published under Vertical, Left to Right, and Front to Back only. There is no separate vibration specification section, measurement summary table, or Reference section in the source.

DVIA-STONE-300PLUS handout for serial 210824R1-2 with Thermo Fisher Krios G4 Cryo-TEM at Peking University Huairou (北大怀柔). Overview, measurement metadata, and STONE-300PLUS internal program screenshots (Vertical, Left to Right, Front to Back) follow the source worksheet verbatim; only those three plots are published as images. There is no separate vibration specification section, Vibration Isolation System model/serial block, measurement summary table, or Reference section in the source.

DVIA-STONE-300P handout (serial 210824R1-3) titled (STONE-300_ 210824R1-3 Set up) with setup 24.07.19 and reporting 24.07.20. Thermo Fisher Krios G4 Cryo-TEM is recorded for Peking University Huairou, with place of installation Beijing. Overview, table fields, and measurement metadata follow the report verbatim; STONE-300 internal program screenshots are published under Vertical, Left to Right, and Front to Back. The worksheet does not include a separate vibration specification section, measurement summary table, or Reference section.

DVIA-M1000 installation report (serial 240517R7) for ZEISS FIB-SEM Crossbeam 550 via YIMO. Overview matches the published form. Equipment condition: The equipment is installed. Published figures include UI-program plots as listed; Reference uses the standard Generic Vibration Criteria markdown table.
