Vibration Isolation Case Studies

July 2025 installation report at Seoul Asan Hospital 4th floor: DVIA-T56 (serial 190329R1-3) beneath a Tomocube HT-2H fluorescence holographic tomography microscope. Published VC, autospectrum, and transmissibility plots by axis; Reference uses the standard VC criteria table.

YIMO-format report — SN 220121R3, 4th tuning, ZEISS Sigma 360 VP FE-SEM at the ZEISS Innovation Center (Shanghai, China). Internal program Transmissibility (Vertical, Left to Right, Front to Back) and equipment photo.

DVIA-M1000 installation report (serial 230105R1-1) for ZEISS MultiSEM at Tsinghua University, Beijing. Overview states the platform is appropriately installed and functioning as intended. End user and location are Tsinghua University and Beijing; equipment is installed/IDLE. Tuning request is shown as a UI capture; Data and Image publishes axis transmissibility plots and an equipment photograph. Reference uses the standard Generic Vibration Criteria markdown table only (no separate reference graphic).

DVIA-M1000 installation report (serial 240509R6) for ZEISS FIB-SEM Crossbeam 550 via YIMO. Overview matches the published form. Equipment condition: The equipment is installed/IDLE. Published figures include UI-program plots as listed; Reference uses the standard Generic Vibration Criteria markdown table.

DVIA-M1000 installation report — EVAN Scanning Auger Electron Spectrometer (serial 250526R4) for Ningbo Institute of Materials, Hangzhou. Overview confirms the platform is appropriately installed and functioning as intended. No vibration specification section on the published form. Equipment condition: The equipment is installed/Turned off. Tuning screenshot, vertical and horizontal transmissibility, equipment photo; Reference presents Generic Vibration Criteria as a markdown table (no separate reference graphic).

DVIA-M3000 (240612R3) installation report — Supergravity Laboratory, Hangzhou, China; QIYUE TECHNOLOGY FIB-SEM SS-HV800. Published Transmissibility plots (Vertical, Left to Right, Front to Back), Tuning Request capture, and equipment photograph. Generic vibration criteria presented as markdown table.
