Vibration Isolation Case Studies

DVIA-MB1000 installation report (serial 230518R2) for JEOL JSM-7001F at POSCO Global R&D center (Songdo). Summary of vibration results (VC-class table), Z/X/Y VC curves and transmissibility plots; Reference uses the standard Generic Vibration Criteria markdown table (reference graphic omitted). Decorative header image from the Word file is not published.

DVIA-MB1000 installation report (serial 230704R4) for ZEISS FE-SEM EVO10 at Jinhae Armed Forces Financial Management Command. Published figures: ZEISS EVO10 specification VC curve (equipment vibration limits), Vertical / Left-to-right / Front-to-back Transmissibility and VC curves. Reference uses the standard Generic Vibration Criteria markdown table only (no separate reference graphic).

DVIA-MB1000 installation report (serial 231123R6) at Tier-1 Semiconductor DSR with ZEISS GeminiSEM 460. On-site restrictions prevented exporting measurement datasets; this public page publishes the manufacturer vibration limits table and Vertical SPEC / Horizontal SPEC diagrams only. VC reference is the standard Generic Vibration Criteria markdown table (no separate reference graphic).

DVIA-MB1000 installation report (serial 231204R8) at a Tier-1 Semiconductor Hwaseong campus analytical lab for ZEISS FE-SEM GeminiSEM 560. Published figures follow the source document: GeminiSEM 560 allowable vibration material and VC-curve diagrams, UI-program Transmissibility (vertical / left-to-right / front-to-back), onsite VC curves under §12.2 for each axis, and the Measurement Summary table. Decorative header raster omitted; Generic Vibration Criteria are published only as the standard markdown Reference table.

MB1000 handout (filename MB1000_231214R7-1, report line MB1000_ 231214R7-1 Set-up) for Wuxi Guangzi end user in Wuxi; ZEISS GeminiSEM 560; setup 23.12.14 / reporting 24.06.05; measurement dated 2024.05.21. Published screenshots only for Vertical, Left to Right, and Front to Back under the M1000 internal program caption — cover/header raster under Set-up omitted.

DVIA-MB3000 (serial 240228R1) with Unisoku USM1400 STM at Mianyang Ninth Hospital. Tuning May 7, 2026; report written May 12, 2026. Vibration specification N/A; equipment turned on/IDLE; UI-program VC, Autospectrum, and Transmissibility per axis; equipment photo not permitted. Reference as Generic Vibration Criteria markdown table only.
