Vibration Isolation Case Studies

DVIA-M1000 serial 230908R3-2 — Westlake University, Thermo Fisher Scientific Helios 5 Hydra in Hangzhou (杭州市). Handout covers set-up on 2024.09.19 with internal-program performance plots for Vertical, Left to Right, and Front to Back; equipment and site photograph under the Set-up block (decorative title-page logos omitted when absent).

DVIA-P4000 installation report (serial 240424R1) at Huahong for an ASML E-beam wafer inspection system (eScan 460). Engineer Chaewon Lee; tuning September 12, 2024; report written September 19, 2024. Vibration specification VC-D. Published vertical, left-to-right, and front-to-back VC curves, narrow-band, and transmissibility plots. Word cover banner (image1) and Reference criteria raster (image11) omitted; Reference uses the standard Generic Vibration Criteria markdown table.

DVIA-M1000 set-up report (serial 230804R5 in report title) for Thermo Fisher FE-SEM Apreo 2S HiVac at Shanghai Electric Guoxuan New Energy, Shanghai. Overview matches the issued form. Published plots: three M1000 internal-program performance screens under Vertical, Left to Right, and Front to Back — the source DOCX uses the same embedded image for Left to Right and Front to Back, so the same public URL is repeated for those two headings. Decorative facility/title-block image under the cover title is omitted from the public page.

DVIA-M1000 installation report (serial 240216R1) for ThermoFisher Helios FIB-SEM at Henan Academy of Sciences, Zhengzhou, China. Overview states the platform is appropriately installed and functioning as intended. Prepared for Henan Academy of Sciences; end user Henan Academy of Science per the form. Equipment condition: The equipment is installed/Turned off. Chaewon Lee, first tuning trial on September 10, 2024; report written June 23, 2025. The published handout has no separate vibration specification section or measurement summary table. Tuning Request UI capture; vertical, left-to-right, and front-to-back transmissibility under Data and Image; Reference uses the standard Generic Vibration Criteria markdown table only (no separate reference graphic).

DVIA-M1000 installation report (serial 240325R2) for Welling Motor in Foshan, China. Overview states the platform is appropriately installed and functioning as intended. Thermo Fisher FIB-SEM Scios 2 Hivac; equipment condition per report: The equipment is installed/ Turn off. Chaewon Lee, tuning date August 28, 2024; report written September 10, 2024. The published report includes Tuning Request UI capture, vertical / left-to-right / front-to-back transmissibility plots, and an on-site equipment photo. The source form does not include End User or Vibration specification sections. Reference uses the standard VC criterion markdown table only (no Generic Vibration Criteria figure).

DVIA-M1000 installation report (serial 240401R1-3) prepared for Southern University of Science and Technology in Shenzhen, China, via YIMO. Overview states the platform is appropriately installed and functioning as intended. HITACHI Regulus8230 SEM; equipment condition The equipment is installed. UI-program transmissibility (vertical, left-to-right, front-to-back). The published case omits the decorative header graphic and the Reference VC diagram image; Reference uses the standard Generic Vibration Criteria markdown table.
