Vibration Isolation Case Studies

DVIA-MB1000 (serial 220330R5-3) installation report prepared for Shanghai Institute of Technology and Technology, Shanghai — Z/X/Y transmissibility plots and equipment photos.

DVIA-MB1000 installation report (serial 220330R5-4) prepared for Shanghai Institute of Technology and Technology, Shanghai, China, with Z-axis, X-axis, and Y-axis transmissibility summary and equipment photos.

TESCAN Korea installation worksheet for AMBER X GMH on DVIA-MB1000 (221202R2) at LB Semicon Pyeongtaek (4F cleanroom). VC curves and transmissibility by axis.

DVIA-MB1000 installation report (serial 230110R2) for ZEISS GeminiSEM 460, prepared for ZEISS KOREA, with tuning and reporting in July 2023 at Tier-1 Semiconductor Hwaseong (11Line 4F development analysis laboratory). Summary of vibration results tabulates floor vs active VC-curve grades by axis and band; Data and Image publishes Z/X/Y VC curves and transmissibility plots. Decorative header raster and the reference-line graphic are omitted; Reference uses the standard Generic Vibration Criteria markdown table only.

Compact MB1000 handout worksheet (serial 230501R3-2). The form leaves target equipment unstated while place of installation and remark read as typed; end user carries a lone dash placeholder. Overview keeps the DVIA-MB1000 wording with measurement site and equipment-model labels open after the colon. Decorative header raster is omitted (no standalone cover blob in DOCX media). Published figures are the internal-program Vertical, Left to Right, and Front to Back screenshots; Reference uses the standard Generic Vibration Criteria markdown table only.

DVIA-MB1000 worksheet (serial 230501R3-3): compact MB1000 internal-program Transmissibility screenshots for Vertical, Left to Right, and Front to Back. Several form fields were unset in the source (target equipment, site, end user); public copy uses N/A. The issued Word file has no Reference / Generic Vibration Criteria appendix — that section is omitted here. Decorative header graphics from the template, if any, were not published.
