Vibration Isolation Case Studies

DVIA-STONE-300PLUS handout (serial 210824R1-2) titled (STONE-300PLUS_ 210824R1-2 Set up) with setup and reporting 25.03.27. Thermo Fisher Krios G4 Cryo-TEM is recorded for Peking University Huairou in Beijing. Overview, measurement metadata, and equipment lines follow the source worksheet verbatim; the STONE-300PLUS internal program section includes Vertical, Left to Right, and Front to Back screenshots only. The decorative image under the title block is omitted from the public page. There is no separate vibration specification section, measurement summary table, or Reference section in the source.

DVIA-M1000 installation report (serial 241220R2). Published figures: vertical-transmissibility, left-to-right-transmissibility, front-to-back-transmissibility, equipment-picture-01. Reference uses the standard Generic Vibration Criteria markdown table.

DVIA-U1000 compact installation worksheet (serial 241204R5) for SpaceX with Thermo Fisher Scientific FIB-SEM Quattro in Hawthorne, California. Setup and reporting 25.03.26; business-trip line 17.12.27~17.12.29; engineer Sungyoon Jung. Overview notes high resonant frequency and passive settings recheck; measurement dated 2025.03.26 (Wednesday). Publishes Vertical, Left to Right, and Front to Back internal-program UI plots; no setup photograph embed in source.

SpaceX Thermo Fisher Scientific FIB-SEM DVIA-U1000 Installation Report

DVIA-M1000 installation report (serial 240930R6) — Thermo Fisher Scientific SEM Apreo 2S. YIMO field package. UI-program transmissibility plots and equipment photo; Reference as markdown VC table.

DVIA-M1000 installation report (serial 250102R2-3). Published figures: tuning-request, vertical-transmissibility, left-to-right-transmissibility, front-to-back-transmissibility. Reference uses the standard Generic Vibration Criteria markdown table.
