Vibration Isolation Case Studies

DVIA-MB1000 worksheet (serial 210524R4) for Thermo Fisher Scientific Helios 5 CX at Visionox (Guangzhou). Operator Choi, HyoungMun; setup 21.05.10 and reporting 21.05.12; measurement date 21.06.23 (Tuesday) with Daeil System research engineer Choi, HyoungMun at Visionox (Guangzhou). The source includes a transmissibility summary table (2 Hz / 5 Hz / 10 Hz) and three MB1000 internal-program plots (Z, X, Y). Decorative header raster after the “MB1000 P232 210524R4” title line is omitted on the public page.

DVIA-MB1000 serial 210309R5 (project P214) for TESCAN Mira reported by /channel partner; installation-site table lists Shanghai university floor 2 while transmissibility and internal-program screenshots were gathered in Shenzhen per the Measurement date block. Figures follow Z axis, X axis, and Y axis as in Word; ornamental title-block photo after the centered heading line is not republished.

Field handout — DVIA-MB1000 serial 201123R3 (P210) for ZEISS Gemini 300 in Shenzhen; end user Tencent. Earlier transmissibility summary (21.03.09, Hubei, ZEISS Evo 18) and MB1000 internal-program Z/X/Y plots from the Word package. Ornamental JPEG after the setup title line is not republished.

DVIA-MB3000 (serial 201012R5, internal P15) remote VEC worksheet for Thermo Fisher Scientific Glacios at Novartis (MA): transmissibility and VC-class summary tables, MB1000 internal program axis plots, and VEC measurement graphics. Setup and measurement 2021-04-21; reporting 2021-04-22; operator Doohyun Kim (DAEIL SYSTEMS, research engineer). Historical business-trip window 2017-12-27~2017-12-29 per report header.

Remote VEC worksheet for DVIA-MB1000 (serial 210302R3, internal P224) under THERMO FISCHER NXQ8000 Mask Aligner at Thermo Fisher Scientific, CA (B1). Operator Doohyun Kim; measurement 2021-04-08; setup and reporting dates as stated on the form; business trip window per header. Publishes equipment photograph, MB1000 internal program axis plots, and VEC measurement axis plots extracted from Word. The source handout has no Reference / Generic Vibration Criteria section — none was added.

MB1000 internal-program worksheet (P220) for TESCAN MIRA at LB Semicon (2F annex laboratory): VC-Class summary table, B&K measurement-chain figures, MB1000 internal-program Z/X/Y transmissibility plots, and floor versus isolated-top VC comparison spectra by axis. Generic Vibration Criteria table and standalone VC curve chart embedded in Word are omitted on the public page in favor of the standard markdown Reference table.
