Vibration Isolation Case Studies

Safran Transmission System LAB, Colombes — JEOL JSM-IT800 on DVIA-ML1000 (250829R2).

DVIA-ML1000 installation report — Beijing University of Aeronautics and Astronautics Unisoku STM (serial 250730R1-1). Overview documents Z-axis VCM issues (Dec 3 / Dec 11 visit), interim tuning with Z2 off and Z3/Z4 matrix sign reversal, and acceptable overall performance with slight horizontal-axis degradation pending full VCM repair. Transmissibility plots (vertical, left-to-right, front-to-back), tuning-request capture, and equipment photo.

DVIA-ML1000 installation report — ZEISS FE-SEM Sigma 360 (serial 250828R5). Overview states the platform is appropriately installed and functioning as intended. Prepared for, End User, and Location are N/A on the form. Equipment Condition The equipment turned on/IDLE; Tuning Request N/A. UI-program transmissibility (vertical, left-to-right, front-to-back) and equipment photo. No vibration-spec screen capture and no measurement summary table on the published form.

DVIA-ML1000 SN 250828R5 — ZEISS Sigma 360; report contains transmissibility plots (Z/X/Y).

DVIA-ML3000 (serial 250805R2) installation report for the Nano Convergence Technology Institute 4F Line with a ZEISS X-ray Microscope Versa 630. Equipment specification is shown as a diagram; measurement summary compares floor versus DVIA-ML3000 in Turned on/IDLE state. VC, autospectrum, and transmissibility plots per axis; Reference uses the standard Generic Vibration Criteria markdown table.

DVIA-ML1000 installation report — Hitachi FE-SEM model SU8600 (serial 250822R5). Overview states the platform is appropriately installed and functioning as intended. Vibration specification N/A; End user and location N/A. Measurement summary compares floor vs on DVIA-ML1000 with SU8600 turned on/IDLE. UI-program VC curves, Autospectrum, and Transmissibility (vertical, left-to-right, front-to-back) and equipment photo.
