Vibration Isolation Case Studies

DVIA-U1000 compact installation worksheet (serial 160628R6) for ZEISS EVO18 at JINSHA SITE MUSEUM, Chengdu, China. Setup 22.10.24 with reporting 22.10.25; measurement 2022.10.24 (Monday); business trip 17.12.27~17.12.29. Published setup photo and U1000 internal-program Z/X/Y measurement screens; decorative Word header ribbon (image1) omitted.

DVIA-UB700 active isolation platform (serial 160628R6) installation report for ZEISS EVO18 at JINSHA SITE MUSEUM, Chengdu, China. Tuning 2022-10-24, report written 2022-10-25; business-trip line 17.12.27~17.12.29. Publication includes Z / X / Y-axis transmissibility plots and equipment photograph. Decorative header bitmap (image1) omitted from the public page.

DVIA-M1000 serial 211020R6-1 SJTU measurement handout dated 2022.10: overview and measurement metadata follow the institute template; onboard equipment remained TBD. The DVIA‑M isolation platform commissioning photo and M1000 internal program performance screenshots for Z, X, and Y are published. Compact header/logo graphics accompanying the masthead paragraph are omitted.

DVIA-M1000 serial 211020R6-3 — Shanghai Jiao Tong University, worksheet target equipment TBD, measurement in Shanghai. Internal-program plots follow Z, X, and Y axis headings as in the source. Decorative header graphic behind the university line and the standalone photograph before the setup tables are not republished.

Abbreviated DVIA-M1000 Set Up worksheet (serial 211026R3-2) for the Shanghai Synchrotron Radiation Facility. Target equipment is TBD on the form; installation site Shanghai; reporting 22.10.25 with measurement on 2022.10.19. Overview states the DVIA-M1000 platform is appropriately installed and functioning as intended. Published figures are three M1000 internal program captures for the Z, X, and Y axes.

Regulus8100 on DVIA-M1000 SN 211220R1 — Shanghai onsite performance check (2022-10-17). Z / X / Y captures from the M1000 internal program.
