Vibration Isolation Case Studies

DVIA-U1000 compact installation worksheet (serial 220718R8) for ZF(China) Investment co.,Ltd. with Prisma E in Shanghai, China. Setup 22.10.18, reporting 22.10.21, business trip 17.12.27~17.12.29; engineer Youngha Lee. Published setup photo and U1000 internal-program Z/X/Y measurement screens; decorative Word header ribbon (image1) omitted.

DVIA-UB700 (S/N 220718R8) installation report prepared for ZF(China) Investment co.,Ltd.; Prisma E equipment in Shanghai, China; engineer Youngha Lee. Tuning date 22.10.18 and report written date 22.10.21 per worksheet. Publication includes Data and Image: Z/X/Y-axis transmissibility plots and equipment photograph; decorative header bitmap (image1) omitted.

LASENSOR SEM5000 on DVIA-M1000 SN 220726R5 — Shanghai onsite performance check (2022-10-19). Z / X / Y captures from the M1000 internal program.

October 2022 installation report following re-tuning of DVIA-UD350 serial 190218R2-1 at Institute for Basic Science (Daejeon), supporting a microscope. Summary table lists Floor vs Active VC-band results; plots cover Z/X/Y VC curves (Floor and Active traces) and transmissibility by axis; Reference publishes the standard VC criteria table.

Installation and vibration measurement report for a DVIA-M3000 at the Shanghai Synchrotron Radiation Facility, with Z / X / Y axis program measurement plots.

DVIA-M1000 serial 220106R7 — SUNLIKY handout for Thermofisher SEM at Zhejiang. Overview matches the supplied form; M1000 internal program performance screenshots for Z axis, X axis, and Y axis from the UI. Cover-only header graphics are not republished.
