DVIA-M1000 abbreviated worksheet (serial 220718R5). Setup dated 23.05.30 and reporting dated 23.06.12; measurement date 2023.05.30 (Tuesday) in ANHUI with operator Hosang Yu from DAEIL SYSTEMS. END USER Anhui GOLD STAR Titanium DIOXIDE(Group) Co., Ltd.; target equipment Apreo 2S HiVac and installation site ANHUI as in the form. The Overview block states the standard DVIA-M1000 sentence only. No vibration specification, equipment status, tuning request, measurement summary table, or Reference section appears in the source. The internal-program section title in the source reads “MB1000 internal program performance measurement result”; published figures are three plots labeled Z axis, X axis, and Y axis. Decorative header graphics and the setup bitmap under the “Set up” line are omitted from public copy.

DVIA-UB700 (serial 230202R1) installation report prepared for BGRIMM TECHNOLOGY GROUP with TESCAN VEGA GMS in Xiamen, China. Tuning date 23.06.07; report written 23.06.12. Publication includes Z / X / Y-axis transmissibility plots and an equipment photograph. Decorative header bitmap from the Word cover block is omitted.

DVIA-UB350 (S/N 220621R1) active vibration isolation platform installation report for Semilab AFM-2000 at ARCHE (147, Annyeong-gil, Byeongjeom-gu, Hwaseong-si, Gyeonggi-do). Transmissibility and VC-curve data are shown for a routine condition and for an enclosure-door disturbance condition. Reference uses the shared Generic Vibration Criteria markdown table (no separate criteria figure).

DVIA-U1000 compact installation worksheet (serial 230202R1) at BGRIMM Technology Group with TESCAN VEGA GMS in Xiamen. Setup 23.06.07, reporting 22.06.12, business-trip line 17.12.27~17.12.29; Overview measurement dated 2023.06.08 (Thursday). Publication includes setup photograph and Z / X / Y internal-program screenshots. Decorative company-line header bitmap (image1) omitted.

DVIA-UB700 (S/N 230116R4) active vibration isolation platform installation report prepared for Foshan Lehua Hengye Kitchen & Bath Co., LTD; Sigma 300 located in CHANGZHOU, China; tuning date June 6, 2023; report written June 12, 2023; engineer Youngha Lee. Published figures from Data and Image: Z/X/Y-axis transmissibility and one equipment site photo; decorative header bitmap from the Word file (image1 / rId8) omitted.

DVIA-U1000 compact installation worksheet (serial 230116R4) at Foshan Lehua Hengye Kitchen & Bath Co., LTD with Sigma 300 in Changzhou. Setup 23.06.06, reporting 22.06.12, business-trip line 17.12.27~17.12.29; Overview measurement dated 2023.06.06 (Tuesday). Publication includes setup photograph and Z / X / Y internal-program screenshots.
