Vibration Isolation Case Studies

DVIA-ML1000 installation report at Changping P3 Laboratory — Thermo Fisher Scientific Cryo-Plasma FIB-SEM Arctis (serial 250715R9). Vertical, left-to-right, and front-to-back transmissibility plots, tuning-request capture, and on-site equipment photo.

DVIA-ML1000 installation report (serial 241016R7).

DVIA-ML1000 installation report — TESCAN SOLARIS X FIB-SEM (serial 250824R1) at STATSCHIPPACK Korea laboratory. Overview describes tuning and vibration measurement, equipment-mounted nested isolator with airflow and vibration from the tool. Vibration limits 10 µm/s (<30 Hz) and 20 µm/s (>30 Hz); measurement setup with Data Physics QUATTRO and PCB 393B05. Measurement summary PASS all axes; VC curves, Autospectrum, and Transmissibility per axis.

DVIA-MB1000 installation tuning for ZEISS MultiSEM FIB-SEM at Tsinghua McGovern (serial 250810R1-1). Tuning-request UI, vertical and horizontal transmissibility plots, and on-site equipment photo.

DVIA-MB1000 (SN 210112R6) tuning and vibration measurement at KIST L0 Building 1F laboratory for a TESCAN Amber X FIB-SEM. Engineer Chaewon Lee (DAEIL SYSTEMS); measurement 2025-10-27; report written 2025-10-28. Includes equipment manufacturer specification diagram, VC / autospectrum / transmissibility plots per axis, site equipment photo, and Generic Vibration Criteria as the standard markdown table (TESCAN header banner and Word reference EMF omitted).

DVIA-M3000 (250708R7) installation report at the Institute of Microsystems with a Thermo Fisher Scientific Talos F200 TEM: tuning request capture, transmissibility results for vertical, left-to-right, and front-to-back axes, equipment photo, and generic vibration criteria as a markdown table.
