Vibration Isolation Case Studies
DAEIL SYSTEMS engineers active vibration isolation systems for the world's most demanding nanoscale imaging and metrology environments.
Series
Equipment Type
Manufacturer
Filtered Case Studies
Beijing University of Aeronautics and Astronautics Unisoku STM DVIA-ML1000 (250730R1-2) Installation Report
DVIA-ML1000 installation report — Beijing University of Aeronautics and Astronautics Unisoku STM (serial 250730R1-2). Overview states the platform is appropriately installed and functioning as intended. Transmissibility plots (vertical, left-to-right, front-to-back), tuning-request capture, and equipment photo.
Hitachi SU8600 FE-SEM DVIA-ML1000 Installation Report (2025-12-01)
Report — SN 250912R6, Hitachi SU8600 FE-SEM. Transmissibility plots (Z / L–R / F–B); equipment photo not permitted on site.
Gedeon Richter JEOL JSM-IT500HR DVIA-ML1000 Installation Report
Gedeon Richter lab — JEOL SEM JSM-IT500HR on DVIA-ML1000 (250829R1).
ZEISS FE-SEM Sigma 560 DVIA-MB1000 (231220R2) Installation Report
DVIA-MB1000 installation report — ZEISS FE-SEM Sigma 560 (serial 231220R2). Overview states the platform is appropriately installed and functioning as intended. Prepared for, end user, and location are not filled on the published form (N/A). Equipment condition: The equipment is installed/IDLE. Tuning request field is blank (N/A). Transmissibility plots (vertical, left to right, front to back), on-site equipment photo, and Reference with Generic Vibration Criteria as a markdown table (reference EMF omitted).
ZEISS FE-SEM Sigma 360 DVIA-MB1000 (241209R2) Installation Report
DVIA-MB1000 installation report — ZEISS FE-SEM Sigma 360 (serial 241209R2). Overview states the platform is appropriately installed and functioning as intended. End user and location are not filled on the published form (N/A). Equipment condition: The equipment is installed/Turned off. Tuning request field is blank (N/A). Transmissibility plots (vertical, left to right, front to back), on-site equipment photo, and Reference with Generic Vibration Criteria as a markdown table (reference graphic omitted; generic criteria image only).
Thermo Fisher Scientific SEM Apreo 2S DVIA-MB1000 (250421R8) Installation Report
DVIA-MB1000 installation report — Thermo Fisher Scientific SEM Apreo 2S (serial 250421R8). Overview states the platform is appropriately installed and functioning as intended. End user, location, and tuning request are not filled on the published form (N/A). Equipment condition: The equipment is installed/Turned off. Transmissibility plots (vertical, left to right, front to back), on-site equipment photo, and Reference section with Generic Vibration Criteria as a markdown table (no separate reference graphic).
