Vibration Isolation Case Studies

DVIA-MB3000 abbreviated worksheet for serial 231004R3-3 with Thermo Fisher Spectra Ultra at Hainan University in Hainan (source file STONE-300_231004R3-3_24.03.05.docx; form wording follows the MB3000 template). Setup dated 24.03.05 and reporting dated 24.03.13; operator Lee, Chaewon in the header block; measurement dated 2024.03.05 (Tuesday) with operator DAEIL SYSTEMS Chaewon Lee. Overview uses the standard DVIA-MB3000 sentence. No vibration specification, equipment condition, tuning request, measurement summary table, or Reference section appears in the source. Internal-program captures are labeled Vertical, Left to Right, and Front to Back under “M3000 internal program performance measurement result.” The JPEG under the Set-up title line was treated as decorative and omitted from the public page.

DVIA-MB3000 (serial 231113R4-1) setup worksheet dated 2024.03.05 at Hainan University with Thermo Fisher Spectra 300: installation summary fields, Overview statement, and M3000 internal program performance plots (Vertical, Left to Right, Front to Back). Operators Chaewon Lee (DAEIL SYSTEMS) and Lee Chaewon per report header; reporting date 2024.03.13.

DVIA-MB1000 (serial 200109R2) installation tuning and vibration measurement at Seoul National University College of Dentistry; Thermo Fisher Scientific SEM Apreo 2 equipment; Jongwon Park and Chaewon Lee (DAEIL SYSTEMS). Measurement with equipment Turned off. Publishes transmissibility curves, RMS velocity VC curves per axis, and an installation photograph. The header strip graphic before Prepared for and the Reference Generic Vibration Criteria raster figure are omitted; Reference uses the site standard VC criteria markdown table.

Pengxin Micro — TESCAN Solaris GMH FIB-SEM on DVIA-M1000 serial 230509R6-3. M1000 internal program performance measurement (Z / X / Y) from the 2024.01.31 handout.

DVIA-MB3000 isolation platform (serial 230818R1-2): on-site worksheet with setup dated 2024.02.01, reporting dated 2024.07.05, remark Good Performance, and three internal-program screenshots (Vertical, Left to Right, Front to Back). End user and installation site fields were left blank on the worksheet (shown as N/A on the web). Engineer Byeonghun Cho (DAEIL SYSTEMS).

DVIA-MB1000 installation report (serial 231128R4) prepared for ZEISS for the Crossbeam 550 installation at ZEISS KOREA Innovation Center (Hwaseong). Overview and conclusion follow the bilingual report wording; vibration results include the Floor vs Active summary table plus UI-program Transmissibility curves, VC curves by axis (Data Physics QUATTRO description graph), manufacturer equipment specification figure, installation photo; Reference publishes the Generic Vibration Criteria markdown table only (reference graphic omitted). Decorative header/logo raster from Word excluded.
