Vibration Isolation Case Studies

DVIA-ULFB700 (S/N 260211R2) installation report — Vertical, Left-to-Right, and Front-to-Back VC curves, Autospectrum, and Transmissibility (equipment turned off).

DVIA-ULF700 (serial 251017R2) installation and vibration tuning with ZEISS FE-SEM Sigma 360 where End User and Location were not disclosed in the report (N/A). Includes vibration specification capture, VC / autospectrum / transmissibility plots, and VC reference table (no decorative header or EMF curve upload).

DVIA-ULF1000 (S/N 251104R1) installation report at Huasheng Lianying Vibration Damping Platform for ZEISS SEM EVO 10; tuning and report written 21 January 2026; 1st trial. Publishes vibration specification text, measurement summary, VC/autospectrum/transmissibility plots for three axes, and equipment photo. Decorative header image and Reference EMF omitted per site rules (Reference uses the standard VC markdown table).

DVIA-ULF1000 (S/N 251112R4) installation and vibration measurement at Tier-1 Semiconductor Fabrication Facility DSR C Tower 3F research lab with ZEISS GeminiSEM 460 FE-SEM.

DVIA-U1000 re-tuning worksheet (serial 220919R6-1) for Goertek Inc. with ZEISS FE-SEM Sigma 300; tuning December 19, 2025, report written January 7, 2026 (Chaewon Lee). Overview cites Z-axis oscillation and gain reduction; location line "-" (N/A). Publishes Vertical, Left to Right, and Front to Back transmissibility UI plots only; equipment picture line Photo Not Allowed; decorative header bitmap and Reference EMF omitted — Reference uses the standard VC markdown table.

DVIA-UB700 (S/N 221024R5) inspection report for ZEISS FE-SEM Sigma 300 at Hanyang University, Natural Sciences Building, Room 112. Turned on/IDLE measurements: vertical, left-to-right, and front-to-back VC curves, autospectra, and transmissibility. LPF tuning on left-to-right and front-to-back removed initial active-mode oscillation; all directions meet vibration specification at pass levels shown in the measurement summary.
