Vibration Isolation Case Studies
DAEIL SYSTEMS engineers active vibration isolation systems for the world's most demanding nanoscale imaging and metrology environments.
Series
Equipment Type
Manufacturer
Filtered Case Studies
ZEISS FE-SEM Sigma 360 DVIA-MB1000 (241209R2) Installation Report
DVIA-MB1000 installation report — ZEISS FE-SEM Sigma 360 (serial 241209R2). Overview states the platform is appropriately installed and functioning as intended. End user and location are not filled on the published form (N/A). Equipment condition: The equipment is installed/Turned off. Tuning request field is blank (N/A). Transmissibility plots (vertical, left to right, front to back), on-site equipment photo, and Reference with Generic Vibration Criteria as a markdown table (reference graphic omitted; generic criteria image only).
Thermo Fisher Scientific SEM Apreo 2S DVIA-MB1000 (250421R8) Installation Report
DVIA-MB1000 installation report — Thermo Fisher Scientific SEM Apreo 2S (serial 250421R8). Overview states the platform is appropriately installed and functioning as intended. End user, location, and tuning request are not filled on the published form (N/A). Equipment condition: The equipment is installed/Turned off. Transmissibility plots (vertical, left to right, front to back), on-site equipment photo, and Reference section with Generic Vibration Criteria as a markdown table (no separate reference graphic).
Ciqtek HEM6000 High Speed SEM DVIA-MB1000 (250514R3) Installation Report
DVIA-MB1000 installation report — Ciqtek High Speed SEM HEM6000 (serial 250514R3), field package. Overview states the platform is appropriately installed and functioning as intended. The published form has no vibration specification section and no measurement summary table. End user and location fields are blank in the report; tuning request section has no content. Equipment condition: The equipment is installed/Turned off. Published figures: vertical, left-to-right, and front-to-back transmissibility; on-site equipment photo; Reference uses the standard Generic Vibration Criteria markdown table.
TESCAN AMBER X FIB-SEM DVIA-MB1000 (250718R1) Installation Report
DVIA-MB1000 installation tuning for TESCAN AMBER X FIB-SEM (serial 250718R1). UI-program transmissibility plots (vertical, left-to-right, front-to-back) and on-site equipment photo.
Hitachi SU8600 FE-SEM DVIA-MB1000 (250515R3) Installation Report
DVIA-MB1000 installation tuning for Hitachi SU8600 FE-SEM (serial 250515R3). UI-program transmissibility plots (vertical, left-to-right, front-to-back) and on-site equipment photo.
ZEISS GeminiSEM 560 FE-SEM DVIA-MB1000 (250714R3) Installation Report
DVIA-MB1000 installation tuning for ZEISS GeminiSEM 560 FE-SEM (serial 250714R3). UI-program transmissibility plots (vertical, left-to-right, front-to-back) and on-site equipment photo.
