Vibration Isolation Case Studies

DVIA-ULF1000 (S/N 250717R1) installation and vibration measurement report at Garden Five Tool Hall 5F, Bruker Korea Demo Lab, with ZEISS GeminiSEM 560 FE-SEM. Measurement 2025-10-13; equipment installed / turned off.

DVIA-ULF1000 (S/N 250717R1) installation and vibration measurement at Bruker Korea Demo Lab for ZEISS FE-SEM Solaris GeminiSEM 560. Tuning on October 13, 2025; report written October 14, 2025. Equipment installed and turned off. Publishes vibration-specification diagram, vertical / left-to-right / front-to-back VC curves, autospectra, and transmissibility plots, installation photo, and markdown VC Reference (no reference illustration).

Huasheng Lianying Vibration Damping Platform (Wuxi, China) YIDONG FE-SEM YF-1801 DVIA-ULF1000 (S/N 250813R2) installation and vibration measurement report — first tuning, equipment installed / turned off.

DVIA-ULFB700 (S/N 250529R5) active vibration isolation platform installation report for ZEISS FE-SEM Sigma 360. Chaewon Lee (DAEIL SYSTEMS) tuned on September 4, 2025; report written September 5, 2025. End User and Location not disclosed in the report form (N/A). Measurement summary table and UI-program VC curves, autospectra, and transmissibility vertical / left-to-right / front-to-back with equipment installed/Turned off; equipment photo and markdown VC Reference (no EMF illustration).

DVIA-ULFB1000 (serial 250711R2) installation report for COXEM (End User) with a ZEISS FE-SEM SUPRA 55VP at Migun Techno World Phase 1, Room 2209, Daejeon. Vibration measurement and tuning on 27 Aug 2025 with the tool installed and turned off. Includes vertical and horizontal vibration specification figures, axis VC curves, autospectra, transmissibility, equipment photo, and the standard VC reference table.

COXEM DVIA-ULFB1000 Installation Report
